Wastegate Upgrades

TiAL 38 mm wastegate with 0.9 Bar spring. Included with this wastegate are 2 adapter plates machined from stainless steel, 12 Allen head bolts & washers (grade 12.9) drilled for safety wire and upgraded gaskets that use a metal fire ring for better sealing properties. Wastegate ships with adapter plates installed and hardware safety wired (.032 Inconel). Includes sufficient safety wire to secure the remaining 8 bolts on the inlet and dump pipe. Includes installation instructions.

NOTE: ‘86 cars fitted with a “1 piece style” crossover pipe may require modification for proper wastegate fitment.

Price: $340.00

P/N: WG-TiAL

TiAL 38mm Wastegate w/ SS Adapter Plates

Home

*Factory Parts* NEW!

Engine Performance

Engine Management

Fuel System Upgrades

Wastegate Upgrades

PLX Devices

Used Parts

Policies

About Us

Wastegate Upgrades

Two adapter plates machined from stainless steel, 12 Allen head bolts & washers (grade 12.9) drilled for safety wire and upgraded gaskets that use a metal fire ring for better sealing properties. Includes safety wire.

Price: $140.00

P/N: WG-AdapterPlates

SS Adapter Plates

Removal and/or replacement of the factory wastegate requires the replacement of the factory sealing rings and crush rings found on the inlet pipe and dump pipe of the wastegate.

Sealing Ring—Crossover to WG elbow pipe                     P/N 93012313404          $14.40
Crush Ring—WG elbow pipe to WG inlet                         P/N 99311119500          $ 7.49
Crush Ring—WG outlet to dump pipe                              P/N 94411120504          $19.95
Sealing Ring—WG dump pipe to exhaust                         P/N 95112313402          $14.95

Price: $56.79

P/N: WG-TiALGaskets
